Amplificatore di potenza

iKON-iK41 è un amplificatore di potenza 4 canali estremamente avanzato: combina una densità ad alta potenza con delle performance audio eccezionali, grazie a controllo di rete e DSP all’avanguardia.

In qualità di amplificatore per line array WPM, TORUS 8 e altri sistemi selezionati, il controller iK41 garantisce un’amplificazione multicanale per determinati diffusori Martin Audio.

Visita il sito del produttore

Applicazione
Live
Numero canali
4
DSP integrata
SI
Tipologia ingressi
AES
Analogico
Dante

General

TYPE: Four-channel Class D amplifier

POWER OUTPUT (*):

    1500W into 2Ω

    1500W into 4Ω

    750W into 8Ω

    325W into 16Ω

    3000W bridged per channel pair, 4Ω

    3000W bridged per channel pair, 8Ω

CV LINE OUTPUT (*):

    685W, 25V line

    1500W, 70V line

    1163W, 100V line

DIGITAL SIGNAL PROCESSING: 96kHz/48kHz DSP on all inputs and outputs

COOLING: Dual vari-speed fans, front-to-back airflow

MAXIMUM AMBIENT TEMPERATURE: 40°C (104°F)

Audio Inputs/Outputs

ANALOGUE IN/LINK (4 CHANNELS):

    4 x female

    4 x male Neutrik™ XLR

ANALOGUE INPUT IMPEDANCE: 20kΩ balanced to ground

MAXIMUM ANALOGUE INPUT LEVEL: +20dBu

AES3 IN/LINK (2 CHANNELS): 1 x female, 1 x male Neutrik™ XLR, balanced

DANTE™ (4 CHANNELS) : 2 x shielded RJ45, primary and secondary

AMPLIFIER OUTPUTS: 4 x Neutrik Speakon™ NL4

Audio Performance

DYNAMIC RANGE:

    >113dBA, analogue input

    >114dBA AES/Dante™ input

FREQUENCY RESPONSE: 7Hz-30kHz (‐2.5dB points, 4Ω load)

TOTAL HARMONIC DISTORTION: <0.05% typical @ 1kHz, 4Ω load

SLEW RATE: >60V per microsecond

DAMPING FACTOR: >800 at amplifier output, ref 8Ω

Control and Monitoring Network

PROTOCOL: Ethernet

CONTROL APPLICATION: Martin Audio VU-NET™

Digital Signal Processing

SAMPLE RATE : 96kHz (48kHz for FIR filter implementation)

PHYSICAL INPUTS:

    4 x analogue

    1 x AES pair with link output

    4 x Dante™ inputs routable to four DSP drive modules

DRIVE MODULE INPUT DSP:

- Input signal routing, delay, gain, HPF, Phase, Mute

- EQ: 2 x low shelf, 6 x PEQ/bandpass and FIR shelving filters

DRIVE MODULE OUTPUT DSP:

- Source, delay, gain, Phase, Mute, crossover filters, limiters

- EQ: low shelf, 8 x PEQ / band pass and shelving filters

Power Supply

TYPE: High performance Series Resonant

AC INPUT OPERATING RANGE: 85 – 240V ~ AC, 47 - 63Hz

MAINS INRUSH CURRENT: 6A at 115V, 12A at 230V (max for <10ms)

MAINS CONNECTOR: Neutrik 32A Powercon™

Physical

DIMENSIONS:

- (W) 482 x (H) 2U/88mm x (D) 441mm

- (W) 18.98in x (H) 2U/3.46in x (D) 17.35in

- (incl handles and optional rear support)

WEIGHT: 12.5kg (27.5lbs)
