AMPLIFICATORE/CONTROLLER 4 CANALI, 2U LIGHTWEIGHT, 4 X 3000W/4 OHM, 96KHZ DSP, NETWORK CONTROL DANTE

Amplificatore/Controller 4 canali, 2 unità rack, peso ridotto, 4 x 3000w/4 ohm, 96KHz DSP.

IK42-DANTE
Array ( [lastname] => [firstname] => [email] => [last_passwd_gen] => [birthday] => [newsletter] => [newsletter_date_add] => [ip_registration_newsletter] => [optin] => [website] => [company] => [siret] => [ape] => [outstanding_allow_amount] => 0 [max_payment_days] => 0 [note] => [is_guest] => 0 [id_shop] => [id_shop_group] => [id_default_group] => 1 [date_add] => [date_upd] => [reset_password_token] => [reset_password_validity] => [vatNumber] => [sdi] => [pec] => [rl_delayedpayment] => [id] => [is_logged] => [gender] => Array ( [type] => [name] => [id] => ) [risk] => Array ( [name] => [color] => [percent] => [id] => ) [addresses] => Array ( ) ) 1

Hai bisogno di maggiori informazioni su questo prodotto?

Contattaci subito


Amplificatore di potenza

iKon iK42 è un amplificatore di potenza estremamente avanzato: combina una densità ad alta potenza con performance audio eccezionali grazie a controllo di rete e DSP all’avanguardia.

In qualità di amplificatore di controllo per line array Wavefront Precision e stage monitor della serie XE, iK42 garantisce un’amplificazione multicanale per determinati diffusori Martin Audio.

Visita il sito del produttore

Applicazione
Live
Numero canali
4
DSP integrata
SI
Tipologia ingressi
AES
Analogico
Dante

General

TYPE: Four-channel Class D amplifier

POWER OUTPUT (*)

    5000W into 2Ω

    3000W into 4Ω

    1500W into 8Ω

    10000W bridged per channel pair, 4Ω

CV LINE OUTPUT (*)

    1250W, 25V line

    3500W, 70V line

    5000W, 100V line

DIGITAL SIGNAL PROCESSING: 96kHz/48kHz DSP on all inputs and outputs

COOLING: Dual vari-speed fans, front-to-back airflow

MAXIMUM AMBIENT TEMPERATURE: 40°C (104°F)

Audio Inputs/Outputs

ANALOGUE IN/LINK (4 CHANNELS)

    4 x female

    4 x male Neutrik™ XLR

ANALOGUE INPUT IMPEDANCE 20kΩ balanced to ground

MAXIMUM ANALOGUE INPUT LEVEL +20dBu

AES3 IN/LINK (2 CHANNELS) 1 x female, 1 x male Neutrik™ XLR, balanced

DANTE™ (4 CHANNELS)  2 x shielded RJ45, primary and secondary

AMPLIFIER OUTPUTS 4 x Neutrik Speakon™ NL4

Audio Performance

DYNAMIC RANGE

    >113dBA, analogue input

    >114dBA AES/Dante™ input

FREQUENCY RESPONSE 7Hz-30kHz (‐2.5dB points, 4Ω load)

TOTAL HARMONIC DISTORTION <0.05% typical @ 1kHz, 4Ω load

SLEW RATE >60V per microsecond

DAMPING FACTOR >800 at amplifier output, ref 8Ω

Control and Monitoring Network

PROTOCOL: Ethernet

CONTROL APPLICATION: Martin Audio VU-NET™

Digital Signal Processing

SAMPLE RATE : 96kHz (48kHz for FIR filter implementation)

PHYSICAL INPUTS

    4 x analogue

    1 x AES pair with link output

    4 x Dante™ inputs routable to four DSP drive modules

DRIVE MODULE INPUT DSP:

- Input signal routing, delay, gain, HPF, Phase, Mute

- EQ: 2 x low shelf, 6 x PEQ/bandpass and FIR shelving filters

DRIVE MODULE OUTPUT DSP:

- Source, delay, gain, Phase, Mute, crossover filters, limiters

- EQ: low shelf, 8 x PEQ / band pass and shelving filters

Power Supply

TYPE: High performance Series Resonant

AC INPUT OPERATING RANGE: 85 – 240V ~ AC, 47 - 63Hz

MAINS INRUSH CURRENT: 6A at 115V, 12A at 230V (max for <10ms)

MAINS CONNECTOR: Neutrik 32A Powercon™

Physical

DIMENSIONS:

- (W) 482 x (H) 2U/88mm x (D) 441mm

- (W) 18.98in x (H) 2U/3.46in x (D) 17.35in

(incl handles and optional rear support)

WEIGHT: 12.5kg (27.5lbs)
